TRINA SOLAR PANELS

• Mono-crystalline Module
• - 330W Power Output
• - 19.9 % Maximum Efficiency
• - 0 - + 5 W Positive Power Tolerance

• High power output
• - Combined with MBB technology

• Outstanding visual appearance
• - Designed with aesthetics in mind
• - Thinner wires that appear all black at a distance

• Half-cell design brings Higher Efficiency
• - Half-Cell layout (120 mono-crystalline) PERC Technology
• - Lower Thermal co-efficients for greater energy production at high operating temperature.
• - Low cell connection power loss due to half-cell layout (120 mono-crystalline)

• Highly reliable due to stringent quality control
• - Over 30 in-house tests (UV, TC, HF etc.)
• - PID resistant
• - 100% EL double inspection

• Certified to withstand the most challenging environmental conditions
• - 2400 Pa negative load
• - 5400 Pa positive load

*2400/2400 is the measured load and the safety factor is 1.5 times

Trina DD06M.08 (II) – 330 W

• Mono-crystalline Module
• 400 W Power Output
• 20.4 % Maximum Efficiency
• 0 - + 5 W Positive Power Tolerance
• High power output
• - Combined with MBB technology.
• - Reduce BOS cost with higher power bin and 1500V system voltage
• Half-cell design brings higher efficiency
• - Half-Cell layout (144 mono-crystalline)
• - Low thermal coefficients for greater energy production at high operating temperature
• - Low cell connection power loss due to half-cell layout (144 mono-crystalline)
• - Passivated Emitter and Rear Cell (PERC Technology)
• Highly reliable due to stringent quality control
• - Over 30 in-house tests (UV, TC, HF etc)
• - Internal test requirement of Trina more stringent than certification authority
• - 100% EL double inspection
• Certificated to withstand the most challenging environmental conditions:
• - 2400 Pa negative load
• - 5400 Pa positive load
• * 2400/5400 is the measured load, and the safety factor is 1.5 times

Trina TSM DE15M (II) – 400 W

• Multi-crystalline Module
• 285 W Power Output
• 17.6 % Maximum Efficiency
• 0 - + 5 W Positive Power Tolerance
• Ideal for large scale installations
• - Reduce BOS cost with higher power bin
• Half-cell design brings higher efficiency
• - Low thermal co-efficients for greater energy production at high operating temperature
• - Low cell connection power loss due to half-cell layout (120 multi-crystalline)
• Highly reliable due to stringent quality control
• - Over 30 in-house tests (UV, TC, HF etc)
• - Internal test requirement of Trina more stringent than certification authority
• - PID resistant
• - 100% EL double inspection
• Certified to withstand the most challenging environmental conditions
• - 2400 Pa negative load
• - 5400 Pa positive load
• *2400/5400 is the measured load, and the safety factor is 1.5 times

Trina TSM PD06H – 285 W
